INDUSTRIAL APPLICATION PUMPS

Overview
The design of Diaphragm pumps is to withstand process industrial requirement for the fluid to be pumped and to efficiently the fluid to transfer. Availability in single and three phase allows the wide range of access. Suitable for corrosive and non-corrosive fluids irrespective of any industrial application. The pumps are designed to meet the major intention of break free operation due to corrosion. Also the pumps are off contamination free operation and self priming capacity. Without bringing any damage it can run on dry conditions as well. Voltage variations are not a major concern in our design. Available in single phase and three phase. These are equipped with Thermal Overload Protection to prevent motor from burning.

Applications
• Mobile dewatering pump feed.
• Sludge application.
• Food processing industry.
• Chemical treatment plant
• Industrial Water treatment
• Petroleum processing industry.
• Distilleries.

Features
• Safety blow off valves are built-in to all pumps as standard.
• Meet present strength and safety requisites.
• Longer reliable operation, lesser maintenance costs
• Best design for rough handling and abrasive materials providing durability and longer life
• pumps are backed up by a comprehensive 12month warranty package.
• Easy to handling, installation & transporting.
• High tensile strength and wetted metal parts are layered to prevent corrosion resistance.

Specifications
• Maximum cycles per minute: 300.
• Differential pressure: 20-150 psi.
• Diaphragm size: 4” to 8”.
• Capacity: 28 to 265 GPM
• Total Diaphragms: single or double.



Overview
Low Flow, Medium Pressure, Positive Displacement Pumps are of swashplate structure. The one piece rotor is supported by high capability roller bearings which offer exceptional life performance. The exclusive running plate and retainer plate improve the unit’s capacity for a wide range of fluids. These heavy-duty pumps are best for fluid handling of water and non-abrasive or general use chemicals. All pumps are constructed from cast iron materials. They attribute stainless steel valves and ball bearing, leather or fabric-reinforced cups. Smooth operation even in voltage variation from 350-440 volts. These are equipped with Thermal Overload Protection to prevent motor from burning.

Applications
• Suitable for clean fluids, slurries.
• Chemicals process industry.
• Petrochemical Processing sector.
• Industrial Water treatment
• Irrigation
• Offshore, marine industry.

Features
• Distinctive structure allows process on a wide range of fluids. i.e. Hydraulic Mineral Oils, Water Emulsions, Water   Glycols, Phosphate Ester, Diesel and other special fluids.
• Heavy duty motor, operates cooler with higher efficiencies.
• Wide range of controls as standard, with many special variants possible to suit specialized applications.
• Overheat protection, out of phase, single phasing, and no load.
• Fast and accurate control response.
• Best design for rough handling and abrasive materials providing durability and longer life.
• Compact overall dimensions with good power to weight ratio.
• Easy to handling, installation & transporting.
• Designed and developed to give long operating life.

Specifications
• Maximum rated Speed: 3000 RPM
• Maximum Operating Pressure: 3500 PSI
• Range of HP: 20 to 95 HP
• Capacity: 4.8 to 35 GPM
• Displacement: 8 to 32 in3/rev



Overview
Design of Industrial Lobe pumps are made to handle close to any viscose fluids, particularly shear perceptive material, at superior pressures than an inside gear pump. At high pressure shaft bearing system with bushings on double sides of the bi-wing rotors to permit higher pressures and also cut down wear & tears on bushes and seals. A variable bearing casing helps to perform simple end clearance adjustment. These pumps accept large ranges of cartridge-style seals from major manufacturers, including single & double mechanical and triple lip seals. The two smaller sizes also accept component single mechanical seals or shaft packing.

Applications
• Distilleries Industry.
• Chemicals process industry.
• Diary.
• Pharmaceuticals.
• Food Processing.
• Offshore, marine industry.

Features
• Enhanced rotor to shaft involute drive spline handles superior torques and optimizes position.
• Rotor container is self-draining with perpendicular ports, reducing risk of contamination & maximizes product    yield.
• Front loading seals are inbuilt- means ease of maintenance and reduced service time.
• Stainless Steel 304 Feet to eliminate corrosion.
• Larger bearings increase pressure capability and bearing life time by up to 50%.
• Heavy duty shafts enable up to 50% longer lifetime.
• No Dead Zones on front cover.
• Easy to handling, installation & transporting.
• Designed and developed to give long operating life.

Specifications
• Port Size: 0.75″ to 8″
• Displacement: 0.016 to 10.0 L/rev.
• Differential pressure: 7 to 31 bar
• Max Speed: 350 to 1000 RPM
• Max Displacement: 0.8 to 190 m3/hr



Overview
Screw pumps are typical double suction self-priming twin screw pumps with external bearings and timing gear transmission. They are designed for the delivery of a variety of fluids in a wide range of viscosity that free of solid substances or with a slight abrasiveness at modest temperature. The flow direction of the fluid shall be determined by the revolution of the power shaft, results in easier and convenient to change the position of the suction and discharge. The rolling bearings are being held by power screw shaft and idle screw shaft. The torque is securely transferred by the timing gears, makes sure no metallic contact and dynamic transfer between the screws, thus no threat to the pump even run dry in a short time.

Applications
• Transportation and Storage Industries.
• Oil Terminals
• Petrochemical Industries.
• Industrial Water treatment
• Chemical Industry.
• Offshore, marine industry.

Features
• Strong self-priming capacity, low NPSHr.
• Heavy duty motor, Low pulsation.
• No agitation to the fluids and no emulsified shear.
• Overheat protection, out of phase, single phasing, and no load.
• Fast and accurate control response.
• Relatively constant flow while pressure or viscosity surging.
• Capacity proportional to the speed and adjustable by frequency converting.
• Direct drive, no speed-reducer in need.
• Changeable flow orientation, High Viscosity Application.

Specifications
• Working temperature: 120 deg C
• Viscosity: 1000 to 15000 cst.
• Range of HP: 20 to 195 HP
• Capacity: 190 to 895 GPM
• Max Displacement: 0.8 to 310 m3/hr

Overview
Jet pumps are being used in wide range of applications such as pumping water from deep wells and regulating fluid flow in a loop system. These category pumps are capable for maximum suction lift of 50 meters depth. Jet pumps are presented in a wide range power and performance rates. Our Jet pumps are designed to withstand the power fluctuation from 160 to 240 VOLTS and the dynamic components used to assemble this pumps guarantee in less vibration and steady performance. These are widely used in industrial, agricultural and residential purpose.

Applications
• Plant services
• Water supply systems
• Liquid transfer
• Ultrapure water systems
• Water reclamation
• Water treatment
• Irrigation
• Air conditioning systems

Features
• Back enclosure assembly and overhaul of the impeller and seal without distorting suction and discharge    connections.
• High quality mechanical shaft seals and o-rings are used in these pumps available for standard pumping    requirements.
• Stainless steel end components & corrosion resistance.
• Close coupled design saves space and simplifies maintenance and installation.
• T op centerline discharge and foot support under casing ensures self-venting.
• High operating efficiency and lesser operating costs.

Specifications
• Suction Size: 1 1/4″ to 1 1/2″
• Discharge Size: 1″
• Range of HP: 1/2 to 3 HP
• Capacity: 1.5 to 19 GPM

Overview
The design of Submersible pumps is to withstand submersion in the fluid to be pumped and to efficiently push the fluid to the surface. Availability in single and multi-stage models allows the wide range of access. Single stage pumps are most commonly found in drainage, sewage and slurry pumping. Whereas Multiple stage submersible pumps are being widely used in water and oil wells. Our design on the pumps is to meet underwater applications so as to avoid priming and foot valve and smooth operation even in voltage variation from 350-440 volts. These are equipped with Thermal Overload Protection to prevent motor from burning.

Applications
• Fountains
• Dewatering
• Wells
• Water supply to residential/commercial high rise buildings
• Industrial Water treatment
• Irrigation

Features
• Heavy duty motor, operates cooler with higher efficiencies
• Overheat protection, out of phase, single phasing, and no load.
• Longer reliable operation, lesser maintenance costs and operate 70,000 hours operation for bearing
• Best design for rough handling and abrasive materials providing durability and longer life
• Double mechanical seals operate in an oil bath providing longer service life and lower maintenance costs
• Easy to handling, installation & transporting.
• High tensile strength and corrosion resistance with SS shaft.

Specifications
• Suction Size: 1 1/4″ to 1 1/2″
• Discharge Size: 1″,2”, 3”
• Range of HP: 3/4 to 5 HP
• Capacity: 8 to 365 GPM
• Head: 8 to 104 Feet
